- Product name：Vacuum capping machine
- Model No：XGK-ZP-1
- Features：
Product Description 1.The vacuum capping machine is suitable for the sealing of the glass bottle of various shapes and specifications, the bottle and the cover are automatically delivered to the vacuum chamber position, then the vacuum chamber is formed, the vacuum is vacuumed, and the cover is tightened. 2.Applicable specifications: three screw cap, four screw cap.
Product specifications
|
Data sheets |
Details |
|
Name and model |
XGK-ZP-1 |
|
Cap closing speed |
800~1200 bottle one hour |
|
Cap diameter |
Φ30≤D≤Φ90mm |
|
Bottle diameter size |
Φ38≤D≤Φ100mm |
|
Bottle height size |
50≤H≤250mm |
|
Power |
1000W |
|
Voltage |
AC220V, single phase, 50/60HZ |
|
Working pressure |
0.6Mpa |
|
Machine size(L*W*H) |
3000*1950*2150mm |
|
Packing size(L*W*H) |
2200*1270*2100mm, 2300*910*1360mm |
|
Net/gross weight |
650/830kg |
|
Basic construction |
SUS304 stainless steel and anodized aluminum alloy, inside support machine frame is painted steel |
