Main parameters of the machine
Data sheets
Details
Name and model
AL-9180B
Automatic double-sided labeling machine
Labeling speed(max)
21m/min
Label length
10-300mm
Label width(max)
180mm
Conveyer chain width
101mm
Applicable product size
Length: 40mm ~ 180mm
Width: 30mm ~ 110mm
Height: 50mm ~ 350mm
Outside diameter of label roll(max)
Φ350mm
Inside diameter of label roll(max)
Φ76mm
Accuracy of labeling
±1mm
Overall size(L*W*H)
3000*1500*1600mm
