Main parameters of the machine
Data sheets
Details
Name and model
AXGZ-SGJY-1 one nozzle simple filling machine
Max filling speed
Filling 200ml, 500~900 pcs/hour, speed will be different when bottle shape and neck size and the filling material forming and other physical property
Applicable bottle diameter size
Φ20≤D≤Φ100mm
Applicable bottle height size
30≤H≤300mm
Filling accuracy
±1%
Filling dose
100~1000ml
Voltage
AC220V, single phase, 50/60HZ
Power
500W
Working pressure
0.6MP
Air consumption
1200L one hour
Net/gross weight
100/150Kgs
Machine size(L*W*H)
2000*1200*1500mm
Machine direction
From left to right
Operation process
Put products on conveyer—>Block bottles—> sensor count the empty bottle—> 1 bottle come into the filling station —>lock bottles —>starting filling —> filling finished —> loose Block bottles—> Output bottles
