- Product name：Bottle unscrambler
- Model No：ALBG-300
- Features：
Product Description 1. It is suitable for automatic transmission of round and square bottles, such as conveyor belt connected to labeling machine, filling machine and capping machine, automatic feeding, improving efficiency; can be applied to the intermediate connection of the assembly line as a buffer platform. Reduce the length of the conveyor belt. 2. The applicable bottle range can be adjusted freely. The bottle conveying speed is 30~100 bottles/min, and the speed can be adjusted to facilitate production arrangement.
Product specifications
Main parameters of the machine
Data sheets
Details
Name and model
ALBG-300 auto bottle unscrambling machine
Sorting speed
30~100pcs/minute
Applicable bottle
Φ20mm≤D≤Φ120mm
Applicable bottle height size
50mm≤H≤200mm
Power
1500W
Voltage
AC220V, single phase, 50/60HZ
Working pressure
need compressed air: 0.5~0.6Mpa
Oversize (L*W*H)
2250*1850*1850mm
Net weight
550kgs
